Original price was: $594.00.$98.99Current price is: $98.99.
- Buy Quality, Live Better
- Nature-friendly materials, 100%.
- Free Shipping, No Compromise on Quality
- Shop with ease, buy with confidence.
- Internal plunger threads
- Snap-in grooved saddles
- Plunger wipers help seal out dirt
- Collar fixture threads
- Two base mounting holes
- Maximum working pressure: 10,000 psi/ 700 bar
- High strength steel construction
- High-flow couplers
- Collar thread protector
| Collapsed Height | 10.63 |
|---|---|
| Operation | Single Acting |
| Brand | BVA Hydraulics |
| Oil Capacity (In³) | 18.77 in |
| Cylinder Capacity (Tons) | 15 tons |
| Manufacturers Part Number | H1506 |
| Package Quantity | 1 |
| Internal Pressure at Capacity | 10000 psi |
| Includes | High Flow Female Coupler |
| Stroke | 5.98 in |
| Cylinder Effective Area (In²) | 3.14 in² |
| Length | 2.75 in |
| Cylinder Bore Diameter | 2 |
| Extended Height | 16.61 |
| Height | 10.63 in |
| Outside Diameter | 2.75 |
| ANSI/ASME Rating | B30.1 |
